Milling is an important part of pharmaceutical production. The major uses and purposes of milling for pharmaceutical production are shown below;

Milling process for active substances

– Equalize active pharmaceutical ingredient (API) particle size

Fine Impact Mill

Fine impact mill 250UPZ in pharma design

– Increase solubility by fine milling

Fluidized Bed Opposed Jet Mill AFG

Fluidized bed opposed jet mill 200AFG in pharma design

Milling process for drug formulations

– Milling of excipient to adjust the particle size prior to mixing allowing for uniform content

Fine Impact Mill UPZ

– Milling and mixing of excipient and pigment

Fine Impact Mill UPZ

– Particle size adjustment of agglomerates

Pharma Mill FM-P

– Milling of API

Spiral Jet Mill AS

Spiral jet mill 100AS in pharma design

Milling process for pharmaceutical development

– Milling of several grams of developmental materials

Desk-top Machine Picoline


Milling of pharmaceutical ingredients, Fine Impact Mill

For APIs and excipients, materials of several mm size is milled to 10 µm particle size using impact mills is common. The Fine Impact Mill UPZ can easily control the particle size of the milled product and is also easy to disassemble and clean. The standard system consistes of a feeder – mill – product collector. Systems operating with cooled air or inert gas have been delivered and sizes from laboratory to production capacities are in use by many pharmaceutical companies.

Jet Mill Integrated into an Isolator System

For poor solubility drugs, increasing bio-availability by milling to particle sizes of several microns increases the specific surface area, which in turn increases the dissolving speed of the drug. Jet mills are commonly used for this application.

There are two types of Jet mill, Spiral Jet Mill AS and Counter Jet Mill AFG. With the Counter Jet Mill AFG, controlling the product particle size can be easily achieved by adjusting the classifier speed, making quality control simple. There is very little build-up of material and wear making the Jet mill suitable to process pharmaceutical ingredients which tend to be very adhesive powders. Milling of API increases the specific surface area and surface energy resulting in an increased potential for dust explosions. Preventive measures such as using inert gas for the milling gas are generally used. For milling of pharmaceutical ingredients using the Spiral Jet Mill AS or Counter Jet Mill AFG, milling in inert gas in a closed loop circuit or installation in an isolator with an inert gas atmosphere is possible.

Jet Mill, Pharma, Pharmaceutical, Malaysia, Hosokawa, Micron

Mill integrated in isolator
